Flexible Flanged Grid Coupling
Flexible Flanged Grid Coupling (T31 Type)
Product Identification:
Flexible Flanged Grid Coupling - T31 Type | Keywords: Double Flange Reinforcement, Ultra-heavy Load Transmission, Firm and Stable
Core Value: Adopting a double flange integrated reinforcement structure design, combined with high-strength snake springs, the flexible flanged grid coupling has super strong torque transmission capacity and structural stability, can withstand ultra-heavy loads and impact loads, and adapts to the core transmission needs under extreme working conditions.
Core Advantages:
The double flange forged integrated structure of the flexible flanged grid coupling has extremely strong rigidity and outstanding deformation resistance, can transmit super large torque, suitable for ultra-heavy load transmission scenarios.
The snake spring is made of high-quality spring steel through special heat treatment, with high elastic limit and excellent fatigue resistance, which can effectively absorb impact loads.
The flange connection surface is precision processed, with good sealing performance, which can isolate dust, oil and other impurities, adapting to harsh working conditions.
The transmission is stable, the deviation compensation capacity is good, which can reduce the installation accuracy requirements of ultra-heavy load equipment.
Material and Process
The main body is forged 40Cr alloy steel, the snake spring is 60Si2Mn spring steel (50CrVA for ultra-heavy load models), the gear ring is subjected to carburizing and quenching + precision grinding process, the surface is subjected to rust and corrosion prevention treatment, and the welds are subjected to non-destructive testing.
Application Scenarios
Suitable for ultra-heavy load transmission systems such as metallurgical mines, heavy machinery, port machinery, marine power, large compressors, covering metallurgy, mining, port, shipping and other industries. The flexible flanged grid coupling is the core transmission component under extreme heavy-load working conditions.
Installation and Maintenance
Double flange bolt fastening installation, equipped with high-strength bolts and anti-loosening washers, with firm connection; daily maintenance needs regular inspection of spring wear and flange connection status, adding special grease, and the maintenance cycle is ≥15,000 hours.
Quality Assurance
ISO9001 quality management system certification, 18-month warranty. It supports customized production according to ultra-heavy load working conditions, and provides torque test reports and structural strength test reports.
