High Speed Diaphragm Coupling
High Speed Diaphragm Coupling (DTE Type)
Product Identification
High Speed Diaphragm Coupling - DTE Type | High Speed Precision, Excellent Dynamic Balance, Low Noise Operation
Core Value: Developed for high-speed precision transmission scenarios, the high speed diaphragm coupling integrates lightweight structure design and high-precision dynamic balance technology. It achieves error-free torque transmission under high-speed working conditions, while effectively suppressing vibration and noise, meeting the needs of core transmission systems of high-end equipment.
Core Advantages:
The dynamic balance accuracy of the high speed diaphragm coupling reaches G2.5 level, and the vibration amplitude is ≤0.1mm/s during high-speed operation, providing a stable operating environment for precision equipment.
The main body is made of alloy steel with a lightweight design, which reduces inertia and improves transmission response speed.
The ultra-thin multi-layer diaphragm elastic structure has uniform deformation, which compensates for installation deviations without affecting transmission accuracy, and achieves contact-free transmission without wear.
It has a wide temperature resistance range, suitable for complex working conditions of -60~200℃, with a protection level of IP55 and strong anti-interference ability.
Material and Process
The main body is made of alloy steel, and the diaphragms are made of high-strength stainless steel. It is processed through multiple processes such as CNC turning, precision grinding and dynamic balance calibration, with surface blackening treatment.
Application Scenarios
Suitable for steam turbines, high-speed centrifuges, aerospace supporting equipment and other fields with strict requirements on speed and precision, it is the core adaptive component of high-speed precision transmission systems using high speed diaphragm couplings.
Installation and Maintenance
Adopts precise positioning assembly structure, installation can be completed by bolt tightening without complex debugging; maintenance-free design, only regular cleaning of surface dust and inspection of diaphragm integrity are needed in daily use, with extremely low maintenance costs.
Quality Assurance
Passed ISO9001 and special certification for precision transmission equipment, with a 1-year warranty. It supports customized production according to equipment speed and torque requirements, and provides dynamic balance test reports.
